Steinkjer Stabling Facility
Steinkjer Stabling Facility Photo: Bane NOR
On this page:
Facility Location
Section: Trondheim S–Bodø, Nordlandsbanen.
Distance from Trondheim: 125,5 km.
Contact Information
Elise Sivertsen
Track Table
| Track | Platform | Comments | ||||||
|---|---|---|---|---|---|---|---|---|
| No. | Type | Length (m) | Passing loop length (m) | Extended option (m) | Length (m) | Height (m) | Width (m) | |
| 1 | Hovedtogspor | 1870 | 330 | 760 | 5 | Sideplattform | ||
| 2 | Togspor | 773 | 607 | |||||
| 3 | Buttspor | 337 | Spor 3 | |||||
| 4 | Øvrige spor | 403 | 222 | Tilhører beredskapsterminal | ||||
| 5 | Øvrige spor | 284 | 157 | Tilhører beredskapsterminal | ||||
| 6 | Buttspor | 282 | 170 | 160,60 | 760 | 6 |
Mellomplattform Spor 6 |
|
| 7 | Buttspor | 294 | Spor 7 | |||||
| 8 | Buttspor | 293 | Spor 8 | |||||
| 13 | Buttspor | 95 | 50 | |||||
| 14 | Buttspor | 357 | ||||||
| 15 | Buttspor | 73 | ||||||
Stabling Capacity
| Spor | Hensettings- lengde (m) |
Antall 110 m hensettingsplasser |
KL-anlegg | Serviceplattform | Sportilgang med bil | Toalettømming til stasjonært anlegg | Vannfylling | Togvarmeanlegg | Merknader om begrensninger og funksjoner |
|---|---|---|---|---|---|---|---|---|---|
| 3 | 296 | 2 | |||||||
| 4 | 221 | 2 | |||||||
| 5 | 157 | 1 | X | ||||||
| 7 | 240 | 2 | X | X | X | X | |||
| 8 | 245 | 2 | X | X | X | X | |||
| 9 | |||||||||
| 15 |
Train Heating Installations
| Installation | Location and Capacity | ||||||
|---|---|---|---|---|---|---|---|
| Installation no. | Capacity (kVA) | Stand no. | Local indentity no. | Serving track no. | Voltage (V) | Frequency (Hz) | Maximal continuous current (A) |
| EL-TVA-000171 | 600 | ||||||
| EL-TVA-000172 | 900 | ||||||
Track Plan
Trac plan for Steinkjer Stabling Facility. Bane NOR
