Narvik Stabling Facility
![Photo of Narvik Stabling Facility](/contentassets/eec5481367804cbbb990c26b7d227b65/narvik.jpg?width=1680&height=1120&quality=80)
Narvik Stabling Facility Photo: Bane NOR
On this page:
Facility Location
Section: Narvik–Riksgrensen (Sverige), Ofotbanen.
Distance from Narvik havn: 3,698 km.
Contact Information
Elise Sivertsen
Track Table
Track | Platform | Comments | ||||||
---|---|---|---|---|---|---|---|---|
No. | Type | Length (m) | Passing loop length (m) | Extended option (m) | Length (m) | Height (m) | Width (m) | |
1 | Hovedtogspor | 349 | 529 | 277 | 600/570 | 9,90 |
Sideplattform Dekker spor 1 og 1 NA |
|
1 | Hovedtogspor | 349 | 529 | 212 | 400 | 4 |
Mellomplattform Dekker spor 1 og 2 NA |
|
2 | Togspor | 462 | 624 | 212 | 400 | 4 |
Mellomplattform Dekker spor 2 og 1 NA |
|
3 | Togspor | 877 | 557 | NA | ||||
3 | Togspor | Spor til LKAB | ||||||
4 | Togspor | 854 | 854 | NA | ||||
4 | Togspor | Spor til LKAB | ||||||
5 | Buttspor | Hensettingspor | ||||||
6 | Buttspor | 100 | Hensettingspor | |||||
11 | Buttspor | NA | ||||||
12 | Buttspor | NA | ||||||
13 | Buttspor | NA |
Stabling Capacity
Get in touch with the contact person for Narvik Stabling Area.
Train Heating Installations
Installation | Location and Capacity | ||||||
---|---|---|---|---|---|---|---|
Installation no. | Capacity (kVA) | Stand no. | Local indentity no. | Serving track no. | Voltage (V) | Frequency (Hz) | Maximal continuous current (A) |
EL-TVA-000049 | 50 | ||||||
EL-TVA-000108 | 50 |
Track Plan
![Track plan Narvik Stabling Facility](/contentassets/d9310f3d25cc4c0da23295269667da86/narvik-hensetting.png?width=1680&quality=80)
Track plan for Narvik Stabling Facility. Bane NOR
