Mysen Stabling Facility
![Photo of Mysen Stabling Facility](/contentassets/3fb11290653c4bb4b0c69e336a9fc128/mysen.jpg?width=1680&height=1120&quality=80)
Mysen Stabling Facility Photo: Jernbanedirektoratet
On this page:
Facility Location
Section: Oslo S–Rakkestad, Østre linje.
Distance from Ski: 39,47 km.
Contact Information
Elise Sivertsen
Track Table
Track | Platform | Comments | ||||||
---|---|---|---|---|---|---|---|---|
No. | Type | Length (m) | Passing loop length (m) | Extended option (m) | Length (m) | Height (m) | Width (m) | |
1 | Hovedtogspor | 649,40 | 502 | 220 | 760 | 3,50 | Sideplattform | |
2 | Togspor | 649,40 | 502 | |||||
3 | Togspor | 443 | 284 | 228 | 760 | 3,50 | Sideplattform | |
4 | Buttspor | 187 | 115 | |||||
5 | Buttspor | 40 | Til lokstall |
Stabling Capacity
Track no. | Stabling length (m) | Number of stabling spots (110 m) | Catenary | Service platform | Track access with car | Toilet waste disposal | Water filling | Pre-heating installation | Washing facility | Notes on limitations and functions |
---|---|---|---|---|---|---|---|---|---|---|
2 | 242 | 2 | X | X | ||||||
3 | 284 | 2 | X | |||||||
4 | 130 | 1 | X |
Train Heating Installations
Installation | Location and Capacity | ||||||
---|---|---|---|---|---|---|---|
Installation no. | Capacity (kVA) | Stand no. | Local indentity no. | Serving track no. | Voltage (V) | Frequency (Hz) | Maximal continuous current (A) |
EL-TVA-000107 | 2000 |
Track Plan
![Track plan Mysen Stabling Facility](/contentassets/b987e48215db41b49af2797139a3eb37/mysen-hensetting.png?width=1680&quality=80)
Track plan for Mysen Stabling Facility. Bane NOR
